500ml Milk Bottling Equipment

Basic Information
Place of Origin: China
Brand Name: OEM
Certification: ISO, CE
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Export Standard Packing
Delivery Time: 30-45 working days
Payment Terms: T/T, L/C
Supply Ability: 15 Sets per Month
Detail Information
Name: Milk Bottle Filling Machine Capacity: 12000-14000 Bottles Per Hour(500ml Bottle)
Size(L*W*H): 4000*2800*2400mm Filling Head: 32 Pcs
Filling Temperature: 85-92℃ Weight: 700KG
Suitable Product: Milk,Beverage Juice/Energy Drink/Tea Power: 7.2KW
High Light:

Monoblock Milk Bottling Equipment

,

500ml Monoblock Bottling Machine

,

Washing Filling And Capping Machine


Product Description

500ml Milk Bottling Equipment





Milk Bottling Equipment​ details:



This Milk Bottling Equipment will be very high, about 85-92℃, so when bottles are delivered about from filling machine, the liquid temperature inside bottle will be still high, 80℃ more. In this situation, our company manufacture this type machine, bottle laying down sterilizer,during bottle moving on the product conveyor, there will be special conveyor belt on one side of bottle, and this belt will gradually it went from upright to parallel to the ground, bottle will also lay down during this situation, then the liquid inside will touch the cap, use high temperature liquid to sterilize the cap inside. Which can save more production cost for customer to find other way to sterilize the cap inside.



This Milk Bottling Equipment will be very high, about 85-92℃, so when bottles are delivered about from filling machine, the liquid temperature inside bottle will be still high, 80℃ more. In this situation, our company manufacture this type machine, bottle laying down sterilizer,during bottle moving on the product conveyor, there will be special conveyor belt on one side of bottle, and this belt will gradually it went from upright to parallel to the ground, bottle will also lay down during this situation, then the liquid inside will touch the cap, use high temperature liquid to sterilize the cap inside. Which can save more production cost for customer to find other way to sterilize the cap inside.



Milk Bottling Machine Features:



1. The control system is equipped with automatic control of liquid level in filling tank.

2. The main machine is controlled by frequency converter, which can adjust the speed of production capacity conveniently.

3. Microelectronic data control, stable performance, easy to operate, more user-friendly.

4.The machine is equipped with overload protection device, which can effectively protect the machine equipment and operator.

5. It adopts automatic cap loading system, with perfect cap feeding technology and protection device.

6. Cylinder for filling power, high productivity, simple structure, easy to maintain.



Milk bottling machine description:



The equipment is integrated with washing, filling and capping, it is suitable for the filling and production of all kinds of fruit juice drinks,milk, energy drinks and tea drinks. with simple adjustment of some parts, the machine can also be used for pure water, mineral water filling production. Microgravity negative pressure filling technology, filling more quickly, stable, accurate, equipped with a perfect reflux system; It is equipped with CIP cleaning system, which can clean the liquid tank, pipeline and other liquid contact places. Using human - machine interface touch screen control, PLC computer control, inverter control technology.



Milk bottling machine parameters:



Item                 RCGF12-12-6  RCGF18-18-6  RCGF24-24-8  RCGF32-32-10 RCGF 40-40-13

Capacity

bottles per hour

2000-3000 4000-5000 7000-8000 9000-11000 12000-14000

Suitable bottle

diameter

50-90mm

200-2000ml

Filling temperature

85-92℃

Machine weight

KG

2500 3500 4500 5000 7000

Machine size

L*W*H (mm)

2400*1600

*2400

2400*1850

*2400

3100*2200

*2400

3600*2500

*2400

4000*2800

*2400
